| Specifications |
| Model |
CS-H80x-R100-8G82WKFL |
| Camera |
| Image Sensor |
1/2.7” + 1/2.9” Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm @ F1.0, viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (1080p) 4mm @ F1.6, viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (4K) |
| PT Angle |
Pan: 340°, Tilt: 70° |
| Minimum Illumination |
0.01 Lux @ (F1.0, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) |
| Lens Mount |
M12 |
| Day / Night Switch |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| BLC |
Supports |
| Black & White Night |
30m / 98ft |
| Video & Audio |
| Max Resolution |
3840 × 2160 |
| Frame Rate |
Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Ultra HD; Quad HD; Full HD;HD. Adaptive bit rate. |
| Audio Bit Rate |
Self-Adaptive |
| Network |
| Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20MHz |
| Security |
64 / 128 - bit WEP, WPA / WPA2, WPA-PSK / WPA2 - PSK |
| Transmission Rate |
11b : 11 Mbps, 11g : 54 Mbps, 11n : 150 Mbps |
| Wi-Fi Pairing |
AP paring |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
| Functions |
| Smart Alarm |
AI-powered human shape detection
AI-powered vehicle shape detection
|
| Customized Alert Area |
Supports |
| Two-way Talk |
Supports |
| Auto Tracking |
Supports |
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Storage |
| Local Storage |
Supports microSD Card (Up to 512 GB) |
| Cloud Storage |
Supports EZVIZ CloudPlay storage (Subscription required) |
| General |
| Operating Conditions |
-30ºC ~ 50ºC Humidity 95% or less (non-condensing) |
| IP Grade |
IP65 |
| Power Supply |
DC 12V/1A |
| Power Consumption |
MAX. 12W |
| Dimensions |
170 × 112 × 154 mm (6.69 × 4.41 × 6.06 inch) |
| Packaging Dimensions |
205 × 176 × 194 mm (8.07 × 6.93 × 7.64 inch) |
| Weight |
Product: 630 g (22.22 oz)
Weight with package: 1035 g (36.5 oz)
|
| In the box |
| In the box |
- H80x Dual 4K Camera |
| - Drill Template |
| - Waterproof Kit |
| - Screw Kit |
| - Power Adapter |
| - Regulatory Information × 2 |
| - Quick Start Guide |
| Certifications |
| Certifications |
CE / UL / WEEE / RoHS / REAC |
